用于50/60HZ交流电源供电的单相电机启动和运行。
| 气候类别/Climate Category | 40/85/21 |
| 适用温度范围/Temp. Range | -40℃~+85℃ |
| 容量范围/Capacitance Range | 0.1μF ~ 15μF |
| 额定电压/Rated Voltage | 110~630V.AC |
| 容量偏差/Capacitance Tolerance | ±5%(J)、±10%(K) |
| 损耗角正切/Dissipation Factor (tgδ) | tgδ ~ 0.001 (at 1kHz) |
| 绝缘电阻/Insulation Resistance | C×Rs≥3000S ( 23Clmin) |
| 阻燃性/Flammability | UL94V-0级 |
| 耐电压/Withstand Voltage | 极间/ Between terminals 2.0Un (10S ) 极壳/ Between terminals and case 2000V.AC |
| 引用标准/Reference to Standard | 符合IEC 61071 GB17702.1 MLC企业标准 |
